Raku Nori-kun 4.6
A battery-operated handheld workbench that can be used in a variety of situations, with manual movement and electric lifting.
- Machine number management product
Features
-
Outriggers automatically ground when ascending -
Equipped with center hanging hook
- No specific self-inspection or special education required
Various safety devices
・Sudden descent prevention device
・Vehicle body tilt angle regulation device
・Overload control device (hydraulic relief type)
・Emergency stop device (emergency stop button)
・Emergency descent device
・Lift warning device
・Double power safety device
・Switch guard
・Foot-operated parking brake (type 3)
・Hand brake (type 4)
Specification
Raku Nori-kun
| Model | ENHL046-3 type | ENHL046-4 type |
|---|---|---|
| Working floor height mm | 615～4,600 | 620～4,600 |
| Mounting dimensions width (mm) | 1115 | 1115 |
| Mounting dimensions length (mm) | 1,450 | 1,530 |
| Storage dimensions width (mm) | 750 | 750 |
| Storage dimensions length (mm) | 1,450 | 1,530 |
| Storage dimensions height (mm) | 1,565 | 1,570 |
| Mass (kg) | 405.0 | 430.0 |
| Max load kN(kgf) | 1.47 (150) | 1.47 (150) |
