Mesh Pallet with casters
Handling Locations
*Click to go to Locations page
Mesh Pallet with casters
Available in three sizes: large, medium and small, with casters for convenient movement.
When storing small materials on-site, they can be stacked even with products in them, leading to space savings on-site.
- Machine number management product
Features
-
Folds compactly. Saves space when not in use
Specification
Mesh Pallet with casters
| Model | SC-2 | W-1 | W-2 |
|---|---|---|---|
| Maximum external dimensions Width mm | 930 | 1,030 | 1,235 |
| Maximum external dimensions length mm | 690 | 840 | 1,040 |
| Maximum external dimensions Height mm | 782 | 952 | 1,002 |
| Pallet minimum inner diameter Width mm | 850 | 950 | 1,150 |
| Pallet minimum inner diameter Length mm | 600 | 750 | 950 |
| Pallet minimum inner diameter Height mm | 530 | 700 | 750 |
| Mesh pitch mm | 50×50 | 50×50 | 50×50 |
| Mass (kg) | 48.0 | 52.0 | 75.0 |
| Number of stacking stages | 2 | 2 | 2 |
| Allowable load When using 1 stage kN (kgf) | 4.90(500) | 4.90(500) | 4.90(500) |
| Allowable load When using 2 stages kN (kgf) | 2.45(250) | 2.45(250) | 2.45(250) |
*Due to the structure of the pallet, dimensions may differ slightly from the listed dimensions.
*Please refrain from returning items with products inside.
